Group | Code | Capacity | CCA (SAE) | CCA (EN) | RC | L | W | H | TH | Layout | Terminal | Holddown | Weight | Pcs/plt |
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
B19 | 32B19R | 32 | 270 | 240 | 48 | 187 | 127 | 200 | 220 | 1 | B | B0 | 8,953 | 160 |
B19 | 32B19L | 32 | 270 | 240 | 48 | 187 | 127 | 200 | 220 | 0 | B | B0 | 8,953 | 160 |
B19 | 40B19R | 35 | 300 | 260 | 52 | 187 | 127 | 200 | 220 | 1 | B | B0 | 9,391 | 160 |
B19 | 40B19L | 35 | 300 | 260 | 52 | 187 | 127 | 200 | 220 | 0 | B | B0 | 9,391 | 160 |
B19 | 40B19FL | 35 | 300 | 260 | 52 | 187 | 135 | 200 | 220 | 0 | B | B1 | 9,408 | 145 |
B19 | 40B19FR | 35 | 300 | 260 | 52 | 187 | 135 | 200 | 222 | 1 | B | B1 | 9,408 | 145 |
B19 | 40B19FLA | 35 | 300 | 260 | 52 | 187 | 135 | 200 | 222 | 0 | B+ADT | B1 | 9,452 | 145 |
B19 | 40B19FRA | 35 | 300 | 260 | 52 | 187 | 135 | 200 | 222 | 1 | B+ADT | B1 | 9,452 | 145 |
B19 | 40B19RS | 35 | 300 | 260 | 52 | 187 | 127 | 200 | 220 | 1 | B | B0 | 9,463 | 160 |
B19 | 40B19LS | 35 | 300 | 260 | 52 | 187 | 127 | 200 | 220 | 0 | B | B0 | 9,463 | 160 |
B19 | 42B19R | 38 | 340 | 300 | 55 | 187 | 127 | 200 | 220 | 1 | B | B0 | 9,516 | 160 |
B19 | 42B19L | 38 | 340 | 300 | 55 | 187 | 127 | 200 | 220 | 0 | B | B0 | 9,516 | 160 |
B19 | 42B19FL | 38 | 340 | 300 | 55 | 187 | 135 | 200 | 220 | 0 | B | B1 | 9,526 | 145 |
B19 | 44B19R | 40 | 370 | 300 | 60 | 187 | 127 | 200 | 220 | 1 | B | B0 | 9,497 | 160 |
B19 | 44B19FL | 40 | 370 | 300 | 60 | 187 | 135 | 200 | 220 | 0 | B | B1 | 9,497 | 145 |
B19 | 44B19RA | 40 | 370 | 300 | 60 | 187 | 127 | 200 | 220 | 1 | B+ADT | B0 | 9,541 | 160 |
B19 | 44B19FLA | 40 | 370 | 300 | 60 | 187 | 135 | 200 | 220 | 0 | B+ADT | B1 | 9,558 | 145 |
B19 | 44B19FR | 40 | 370 | 330 | 60 | 187 | 135 | 200 | 220 | 1 | B | B1 | 9,514 | 145 |
B24 | 50B24L | 40 | 370 | 330 | 60 | 235 | 127 | 200 | 220 | 0 | B | B0 | 10,878 | 115 |
B24 | 50B24R | 40 | 370 | 330 | 60 | 235 | 127 | 200 | 220 | 1 | B | B0 | 10,878 | 115 |
B24 | 50B24RS | 40 | 370 | 330 | 60 | 235 | 127 | 200 | 220 | 1 | A | B0 | 10,945 | 115 |
B24 | 50B24LS | 40 | 370 | 330 | 60 | 235 | 127 | 200 | 220 | 0 | A | B0 | 10,945 | 115 |
B24 | 50B24FLA | 40 | 370 | 330 | 60 | 235 | 135 | 200 | 222 | 0 | B+ADT | B1 | 10,924 | 115 |
B24 | 50B24FRA | 40 | 370 | 330 | 60 | 235 | 135 | 200 | 222 | 1 | B+ADT | B1 | 10,924 | 115 |
B24 | 55B24R | 45 | 430 | 360 | 75 | 235 | 127 | 200 | 220 | 1 | B | B0 | 11,775 | 115 |
B24 | 55B24RA | 45 | 430 | 360 | 75 | 235 | 127 | 200 | 220 | 1 | B+ADT | B0 | 11,819 | 115 |
B24 | 55B24L | 45 | 430 | 360 | 75 | 235 | 127 | 200 | 220 | 0 | B | B0 | 11,775 | 115 |
B24 | 55B24LA | 45 | 430 | 360 | 75 | 235 | 127 | 200 | 220 | 0 | B+ADT | B0 | 11,819 | 115 |
B24 | 55B24RS | 45 | 430 | 360 | 75 | 235 | 127 | 200 | 220 | 1 | A | B0 | 11,841 | 115 |
B24 | 55B24LS | 45 | 430 | 360 | 75 | 235 | 127 | 200 | 220 | 0 | A | B0 | 11,841 | 115 |
B24 | 55B24FLA | 45 | 430 | 360 | 71 | 235 | 135 | 200 | 222 | 0 | B+ADT | B1 | 11,814 | 115 |
B24 | 55B24FRA | 45 | 430 | 360 | 71 | 235 | 135 | 200 | 222 | 1 | B+ADT | B1 | 11,814 | 115 |
B24 | 60B24L | 48 | 470 | 420 | 75 | 235 | 127 | 200 | 220 | 0 | B | B0 | 11,67 | 115 |
B24 | 60B24R | 48 | 470 | 420 | 75 | 235 | 127 | 200 | 220 | 1 | B | B0 | 11,67 | 115 |
D20 | 50D20L | 50 | 450 | 390 | 80 | 200 | 172 | 200 | 220 | 0 | A | B1 | 12,896 | 115 |
D20 | 50D20R | 50 | 450 | 390 | 80 | 200 | 172 | 200 | 220 | 1 | A | B1 | 12,896 | 115 |
D23 | 54D23R | 55 | 500 | 480 | 90 | 231 | 172 | 200 | 220 | 1 | A | B1 | 14,474 | 90 |
D23 | 54D23L | 55 | 500 | 480 | 90 | 231 | 172 | 200 | 220 | 0 | A | B1 | 14,474 | 90 |
D23 | 55D23R | 60 | 550 | 480 | 100 | 231 | 172 | 200 | 220 | 1 | A | B1 | 14,921 | 90 |
D23 | 55D23L | 60 | 550 | 480 | 100 | 231 | 172 | 200 | 220 | 0 | A | B1 | 14,921 | 90 |
D23 | 75D23R | 65 | 580 | 540 | 110 | 231 | 172 | 200 | 220 | 1 | A | B1 | 15,734 | 90 |
D23 | 75D23L | 65 | 580 | 540 | 110 | 231 | 172 | 200 | 220 | 0 | A | B1 | 15,734 | 90 |
D26 | 48D26R | 50 | 430 | 360 | 80 | 258 | 172 | 200 | 220 | 1 | A | B1 | 14,809 | 90 |
D26 | 48D26L | 50 | 430 | 360 | 80 | 258 | 172 | 200 | 220 | 0 | A | B1 | 14,809 | 90 |
D26 | 55D26R | 60 | 550 | 480 | 100 | 258 | 172 | 200 | 220 | 1 | A | B1 | 15,972 | 90 |
D26 | 55D26L | 60 | 550 | 480 | 100 | 258 | 172 | 200 | 220 | 0 | A | B1 | 15,972 | 90 |
D26 | 75D26R | 65 | 580 | 540 | 110 | 258 | 172 | 200 | 220 | 1 | A | B1 | 16,807 | 90 |
D26 | 75D26L | 65 | 580 | 540 | 110 | 258 | 172 | 200 | 220 | 0 | A | B1 | 16,807 | 90 |
D26 | 80D26R | 70 | 600 | 540 | 130 | 258 | 172 | 200 | 220 | 1 | A | B1 | 17,07 | 90 |
D26 | 80D26L | 70 | 600 | 540 | 130 | 258 | 172 | 200 | 220 | 0 | A | B1 | 17,07 | 90 |
D26 | 90D26L | 75 | 630 | 600 | 130 | 258 | 172 | 200 | 220 | 0 | A | B1 | 17,56 | 90 |
D26 | 90D26R | 75 | 630 | 600 | 130 | 258 | 172 | 200 | 220 | 1 | A | B1 | 17,56 | 90 |
D31 | 60D31L | 65 | 560 | 480 | 120 | 303 | 172 | 200 | 220 | 0 | A | B1 | 18,13 | 75 |
D31 | 60D31R | 65 | 560 | 480 | 120 | 303 | 172 | 200 | 220 | 1 | A | B1 | 18,13 | 75 |
D31 | 65D31R | 70 | 600 | 540 | 120 | 303 | 172 | 200 | 220 | 1 | A | B1 | 18,511 | 75 |
D31 | 65D31L | 70 | 600 | 540 | 120 | 303 | 172 | 200 | 220 | 0 | A | B1 | 18,511 | 75 |
D31 | 75D31L | 75 | 630 | 600 | 130 | 303 | 172 | 200 | 220 | 0 | A | B1 | 19,178 | 75 |
D31 | 75D31R | 75 | 630 | 600 | 130 | 303 | 172 | 200 | 220 | 1 | A | B1 | 19,178 | 75 |
D31 | 95D31R | 80 | 670 | 640 | 130 | 303 | 172 | 200 | 220 | 1 | A | B1 | 19,87 | 75 |
D31 | 95D31L | 80 | 670 | 640 | 130 | 303 | 172 | 200 | 220 | 0 | A | B1 | 19,87 | 75 |
D31 | 105D31R | 90 | 750 | 720 | 150 | 303 | 172 | 200 | 220 | 1 | A | B1 | 20,796 | 75 |
D31 | 105D31L | 90 | 750 | 720 | 150 | 303 | 172 | 200 | 220 | 0 | A | B1 | 20,796 | 75 |
D31 | 115D31L | 95 | 830 | 760 | 170 | 303 | 172 | 200 | 220 | 0 | A | B1 | 21,931 | 75 |
D31 | 115D31R | 95 | 830 | 760 | 170 | 303 | 172 | 200 | 220 | 1 | A | B1 | 21,931 | 75 |
D33 | MF100R | 100 | 830 | 760 | 185 | 326 | 172 | 203 | 223 | 1 | A | B0 | 23,109 | 60 |
D33 | MF100L | 100 | 830 | 760 | 185 | 326 | 172 | 203 | 223 | 0 | A | B0 | 23,109 | 60 |
E41 | 95E41R | 100 | 830 | 760 | 180 | 408 | 172 | 210 | 230 | 1 | A | B0 | 25,383 | 50 |
E41 | 95E41L | 100 | 830 | 760 | 180 | 408 | 172 | 210 | 230 | 0 | A | B0 | 25,383 | 50 |
E41 | 115E41R | 110 | 900 | 800 | 200 | 408 | 172 | 210 | 230 | 1 | A | B0 | 26,581 | 50 |
E41 | 115E41L | 110 | 900 | 800 | 200 | 408 | 172 | 210 | 230 | 0 | A | B0 | 26,581 | 50 |
F51 | 135F51R | 120 | 870 | 850 | 230 | 506 | 182 | 213 | 233 | 4 | A | B0 | 33,427 | 40 |
F51 | 135F51L | 120 | 870 | 850 | 230 | 506 | 182 | 213 | 233 | 3 | A | B0 | 33,427 | 40 |
G51 | 160G51R | 150 | 1000 | 900 | 300 | 506 | 215 | 213 | 233 | 4 | A | B0 | 39,239 | 35 |
G51 | 160G51L | 150 | 1000 | 900 | 300 | 506 | 215 | 213 | 233 | 3 | A | B0 | 39,239 | 35 |
G51 | 165G51R | 170 | 1050 | 950 | 325 | 506 | 215 | 213 | 233 | 4 | A | B0 | 41,698 | 35 |
G51 | 165G51L | 170 | 1050 | 950 | 325 | 506 | 215 | 213 | 233 | 3 | A | B0 | 41,698 | 35 |
H52 | 210H52R | 200 | 1200 | 1100 | 430 | 509 | 274 | 220 | 240 | 4 | A | B0 | 50,989 | 30 |
H52 | 210H52L | 200 | 1200 | 1100 | 430 | 509 | 274 | 220 | 240 | 3 | A | B0 | 50,989 | 30 |
H52 | 245H52L | 220 | 1400 | 1300 | 460 | 509 | 274 | 220 | 240 | 3 | A | B0 | 55,121 | 30 |
H52 | 245H52R | 220 | 1400 | 1300 | 460 | 509 | 274 | 220 | 240 | 4 | A | B0 | 55,121 | 30 |
Group | Code | Capacity | CCA SAE | CCA EN | RC | L | W | H | TH | Layout | Terminal | Holddown | Weight | Pcs/plt |
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
LB1 | 53518 | 35 | 360 | 330 | 58 | 208 | 173 | 175 | 175 | 0 | A | B13 | 10,560 | 110 |
LB1 | 53519 | 35 | 360 | 330 | 58 | 208 | 173 | 175 | 175 | 1 | A | B13 | 10,560 | 110 |
LB1 | 53624 | 36 | 360 | 330 | 60 | 208 | 173 | 175 | 175 | 0 | A | B1 | 10,551 | 110 |
LB1 | 53638 | 36 | 360 | 330 | 60 | 208 | 173 | 175 | 175 | 1 | A | B1 | 10,551 | 110 |
LB1 | 53646 | 36 | 360 | 330 | 60 | 207 | 173 | 175 | 175 | 0 | A | B13 | 10,560 | 110 |
LB1 | 54316 | 43 | 440 | 400 | 70 | 207 | 173 | 175 | 175 | 0 | A | B13 | 11,519 | 110 |
LB1 | 54321 | 43 | 480 | 450 | 72 | 208 | 173 | 175 | 175 | 0 | A | B13 | 11,768 | 110 |
LB1 | 54322 | 43 | 480 | 450 | 72 | 208 | 173 | 175 | 175 | 1 | A | B13 | 11,768 | 110 |
LB1 | 55021 | 50 | 480 | 450 | 71 | 207 | 173 | 175 | 175 | 0 | A | B13 | 11,768 | 110 |
L1 | 54459 | 44 | 410 | 390 | 73 | 208 | 173 | 190 | 190 | 0 | A | B13 | 11,908 | 110 |
L1 | 54464 | 44 | 410 | 390 | 73 | 208 | 173 | 190 | 190 | 1 | A | B13 | 11,908 | 110 |
L1 | 55054 | 50 | 430 | 420 | 80 | 208 | 173 | 190 | 190 | 0 | A | B13 | 12,280 | 110 |
L1 | 55055 | 50 | 430 | 420 | 80 | 208 | 173 | 190 | 190 | 1 | A | B13 | 12,280 | 110 |
LB2 | 54518 | 45 | 430 | 390 | 75 | 242 | 173 | 175 | 175 | 1 | A | B14 | 12,531 | 90 |
LB2 | 54519 | 45 | 430 | 390 | 75 | 242 | 173 | 175 | 175 | 0 | A | B14 | 12,531 | 90 |
LB2 | 55040 | 50 | 480 | 450 | 83 | 242 | 173 | 175 | 175 | 0 | A | B13 | 12,780 | 90 |
LB2 | 55457 | 54 | 500 | 480 | 90 | 242 | 173 | 175 | 175 | 0 | A | B13 | 13,494 | 90 |
LB2 | 55458 | 54 | 500 | 480 | 90 | 242 | 173 | 175 | 175 | 1 | A | B13 | 13,494 | 90 |
LB2 | 56009 | 60 | 540 | 510 | 100 | 242 | 173 | 175 | 175 | 0 | A | B13 | 13,894 | 90 |
LB2 | 56009R | 60 | 540 | 510 | 100 | 242 | 173 | 175 | 175 | 1 | A | B13 | 13,894 | 90 |
LB2 | 56277 | 62 | 570 | 540 | 100 | 242 | 173 | 175 | 175 | 0 | A | B13 | 14,228 | 90 |
LB2 | 56278 | 62 | 570 | 540 | 100 | 242 | 173 | 175 | 175 | 1 | A | B13 | 14,228 | 90 |
LB2 | 56277 | 62 | 570 | 540 | 100 | 242 | 173 | 175 | 175 | 0 | A | B13 | 14,228 | 90 |
L2 | 55559 | 55 | 500 | 480 | 92 | 242 | 173 | 190 | 190 | 0 | A | B13 | 14,057 | 90 |
L2 | 55565 | 55 | 500 | 480 | 92 | 242 | 173 | 190 | 190 | 1 | A | B13 | 14,057 | 90 |
L2 | 56219 | 62 | 580 | 540 | 103 | 242 | 173 | 190 | 190 | 0 | A | B13 | 15,140 | 90 |
L2 | 56220 | 62 | 580 | 540 | 103 | 242 | 173 | 190 | 190 | 1 | A | B13 | 15,140 | 90 |
LB3 | 55414 | 54 | 500 | 480 | 90 | 276 | 173 | 175 | 175 | 0 | A | B13 | 14,692 | 75 |
LB3 | 55415 | 54 | 500 | 480 | 90 | 276 | 173 | 175 | 175 | 1 | A | B13 | 14,692 | 75 |
LB3 | 56318 | 63 | 580 | 540 | 105 | 276 | 173 | 175 | 175 | 0 | A | B14 | 15,376 | 75 |
LB3 | 56330 | 63 | 580 | 540 | 105 | 276 | 173 | 175 | 175 | 0 | A | B13 | 15,376 | 75 |
LB3 | 56821 | 68 | 630 | 570 | 113 | 276 | 173 | 175 | 175 | 1 | A | B13 | 15,978 | 75 |
LB3 | 56828 | 68 | 630 | 570 | 113 | 276 | 173 | 175 | 175 | 0 | A | B13 | 15,978 | 75 |
LB3 | 57213 | 72 | 670 | 640 | 120 | 276 | 173 | 175 | 175 | 0 | A | B13 | 16,287 | 75 |
LB3 | 57212 | 72 | 670 | 640 | 120 | 276 | 173 | 175 | 175 | 1 | A | B13 | 16,287 | 75 |
L3 | 56638 | 66 | 580 | 540 | 110 | 276 | 173 | 190 | 190 | 0 | A | B13 | 16,593 | 75 |
L3 | 56640 | 66 | 580 | 540 | 110 | 276 | 173 | 190 | 190 | 1 | A | B13 | 16,593 | 75 |
L3 | 57219 | 72 | 630 | 610 | 120 | 276 | 173 | 190 | 190 | 1 | A | B13 | 17,170 | 75 |
L3 | 57220 | 72 | 630 | 610 | 120 | 276 | 173 | 190 | 190 | 0 | A | B13 | 17,170 | 75 |
L3 | 57412 | 74 | 700 | 680 | 123 | 276 | 173 | 190 | 190 | 0 | A | B13 | 17,549 | 75 |
L3 | 57413 | 74 | 700 | 680 | 123 | 276 | 173 | 190 | 190 | 1 | A | B13 | 17,549 | 75 |
LB4 | 57539 | 75 | 710 | 640 | 130 | 315 | 173 | 175 | 175 | 0 | A | B13 | 18,054 | 60 |
LB4 | 58014 | 80 | 750 | 680 | 140 | 315 | 173 | 175 | 175 | 0 | A | B13 | 18,338 | 60 |
L4 | 58043 | 80 | 670 | 640 | 140 | 315 | 173 | 190 | 190 | 0 | A | B13 | 19,325 | 60 |
L4 | 58043R | 80 | 670 | 640 | 140 | 315 | 173 | 190 | 190 | 1 | A | B13 | 19,325 | 60 |
L4 | 59042 | 90 | 750 | 720 | 170 | 315 | 173 | 190 | 190 | 0 | A | B13 | 20,477 | 60 |
L4 | 59043 | 90 | 750 | 720 | 170 | 315 | 173 | 190 | 190 | 1 | A | B13 | 20,477 | 60 |
LB5 | 58515 | 85 | 750 | 720 | 142 | 353 | 173 | 175 | 175 | 0 | A | B13 | 19,780 | 60 |
LB5 | 59015 | 90 | 780 | 740 | 150 | 353 | 173 | 175 | 175 | 0 | A | B13 | 20,180 | 60 |
L5 | 58821 | 88 | 710 | 680 | 147 | 353 | 173 | 190 | 190 | 1 | A | B13 | 21,077 | 60 |
L5 | 58827 | 88 | 710 | 680 | 147 | 353 | 173 | 190 | 190 | 0 | A | B13 | 21,077 | 60 |
L5 | 59218 | 92 | 750 | 720 | 153 | 353 | 173 | 190 | 190 | 0 | A | B13 | 21,745 | 60 |
L5 | 59219 | 92 | 750 | 720 | 153 | 353 | 173 | 190 | 190 | 1 | A | B13 | 21,745 | 60 |
L5 | 60044 | 100 | 870 | 850 | 167 | 353 | 173 | 190 | 190 | 0 | A | B13 | 23,388 | 60 |
L5 | 60044R | 100 | 870 | 850 | 167 | 353 | 173 | 190 | 190 | 1 | A | B13 | 23,388 | 60 |
B19 | 53520F | 35 | 330 | 300 | 58 | 187 | 135 | 200 | 220 | 0 | B | B1 | 8,953 | 145 |
B19 | 53520 | 35 | 330 | 300 | 58 | 187 | 127 | 200 | 220 | 0 | B | B0 | 8,953 | 160 |
B19 | 53521 | 35 | 330 | 300 | 52 | 187 | 127 | 200 | 220 | 0 | A | B0 | 9,008 | 160 |
B19 | 53522 | 35 | 330 | 300 | 58 | 187 | 127 | 200 | 220 | 1 | B | B0 | 9,008 | 160 |
B24 | 54523 | 45 | 430 | 360 | 75 | 235 | 127 | 200 | 220 | 0 | A | B0 | 11,841 | 120 |
B24 | 54524 | 45 | 430 | 360 | 75 | 235 | 127 | 200 | 220 | 1 | A | B0 | 11,841 | 120 |
B24 | 54551 | 45 | 430 | 360 | 75 | 235 | 127 | 200 | 220 | 1 | B+ADT | B0 | 11,775 | 115 |
B24 | 54584 | 45 | 430 | 360 | 75 | 235 | 127 | 200 | 220 | 0 | B+ADT | B0 | 11,775 | 115 |
D20 | 55041 | 50 | 450 | 390 | 80 | 200 | 172 | 200 | 220 | 0 | A | B1 | 12,896 | 115 |
D20 | 55042 | 50 | 450 | 390 | 80 | 200 | 172 | 200 | 220 | 1 | A | B1 | 12,896 | 115 |
D23 | 56068 | 60 | 500 | 480 | 100 | 231 | 172 | 200 | 220 | 0 | A | B1 | 14,693 | 90 |
D23 | 56069 | 60 | 500 | 480 | 100 | 231 | 172 | 200 | 220 | 1 | A | B1 | 14,693 | 90 |
D26 | 56048 | 60 | 500 | 480 | 100 | 266 | 172 | 200 | 220 | 0 | A | B9 | 15,730 | 80 |
D26 | 56049 | 60 | 500 | 480 | 100 | 266 | 172 | 200 | 220 | 1 | A | B9 | 15,730 | 80 |
D26 | 57024 | 70 | 600 | 540 | 117 | 266 | 172 | 200 | 220 | 1 | A | B9 | 17,062 | 80 |
D26 | 57029 | 70 | 600 | 540 | 117 | 266 | 172 | 200 | 220 | 0 | A | B9 | 17,062 | 80 |
D31 | 57512 | 75 | 630 | 600 | 125 | 303 | 172 | 200 | 220 | 0 | A | B1 | 19,178 | 75 |
D31 | 57513 | 75 | 630 | 600 | 125 | 303 | 172 | 200 | 220 | 1 | A | B1 | 19,178 | 75 |
D31 | 58513 | 85 | 700 | 680 | 142 | 303 | 172 | 200 | 220 | 0 | A | B1 | 20,361 | 75 |
D31 | 58514 | 85 | 700 | 680 | 142 | 303 | 172 | 200 | 220 | 1 | A | B1 | 20,361 | 75 |
D31 | 59518 | 95 | 750 | 720 | 158 | 303 | 172 | 200 | 220 | 0 | A | B1 | 21,171 | 75 |
D31 | 59519 | 95 | 750 | 720 | 158 | 303 | 172 | 200 | 220 | 1 | A | B1 | 21,171 | 75 |
D31 | 60045 | 100 | 830 | 760 | 180 | 303 | 172 | 200 | 220 | 0 | A | B1 | 22,183 | 75 |
D31 | 60046 | 100 | 830 | 760 | 180 | 303 | 172 | 200 | 220 | 1 | A | B1 | 22,183 | 75 |
D33 | 59615 | 96 | 800 | 760 | 160 | 326 | 172 | 203 | 223 | 0 | A | B1 | 22,473 | 60 |
D33 | 59616 | 96 | 800 | 760 | 160 | 326 | 172 | 203 | 223 | 1 | A | B1 | 22,473 | 60 |
E41 | 60016 | 100 | 830 | 760 | 180 | 408 | 172 | 210 | 230 | 0 | A | B0 | 25,383 | 60 |
A | 62034 | 120 | 750 | 680 | 230 | 514 | 189 | 196 | 215 | 3 | A | B0 | 33,386 | 40 |
A | 62035 | 120 | 750 | 680 | 230 | 514 | 189 | 196 | 215 | 3 | A | B13 | 33,386 | 40 |
A | 62035F | 120 | 750 | 680 | 230 | 514 | 189 | 196 | 215 | 3 | A | B1 | 33,413 | 40 |
A | 62038 | 120 | 750 | 680 | 230 | 514 | 189 | 196 | 215 | 4 | A | B0 | 33,386 | 40 |
A | 63530 | 135 | 800 | 720 | 250 | 514 | 189 | 196 | 215 | 3 | A | B0 | 34,848 | 40 |
A | 63532 | 135 | 800 | 720 | 250 | 514 | 189 | 196 | 215 | 4 | A | B0 | 34,848 | 40 |
A | 64589 | 145 | 900 | 800 | 260 | 514 | 189 | 196 | 215 | 3 | A | B0 | 35,607 | 40 |
A | 64589F | 145 | 900 | 800 | 260 | 514 | 189 | 196 | 215 | 3 | A | B1 | 35,607 | 40 |
B | 64317-J | 143 | 1000 | 900 | 272 | 506 | 215 | 194 | 215 | 3 | A | B0 | 36,357 | 35 |
B | 64317 | 143 | 1000 | 900 | 270 | 514 | 223 | 196 | 215 | 3 | A | B0 | 41,162 | 30 |
B | 64317F | 143 | 1000 | 900 | 270 | 514 | 223 | 196 | 215 | 3 | A | B1 | 41,223 | 30 |
B | 66016 | 160 | 1000 | 900 | 320 | 514 | 223 | 196 | 215 | 3 | A | B0 | 41,941 | 30 |
B | 66017 | 160 | 1000 | 900 | 320 | 514 | 223 | 196 | 215 | 4 | A | B0 | 41,941 | 30 |
B | 67018 | 170 | 1050 | 950 | 320 | 514 | 223 | 196 | 215 | 3 | A | B0 | 42,681 | 30 |
B | 67019 | 170 | 1050 | 950 | 320 | 514 | 223 | 196 | 215 | 4 | A | B0 | 42,681 | 30 |
B | 68032 | 180 | 1100 | 1000 | 370 | 514 | 223 | 196 | 215 | 3 | A | B0 | 43,998 | 30 |
B | 68032F | 180 | 1100 | 1000 | 370 | 514 | 223 | 196 | 215 | 3 | A | B1 | 44,059 | 30 |
B | 68033 | 180 | 1100 | 1000 | 370 | 514 | 223 | 196 | 215 | 4 | A | B0 | 43,998 | 30 |
B | 68035 | 180 | 1100 | 1000 | 370 | 514 | 223 | 196 | 215 | 3 | A | B13 | 44,061 | 30 |
B | 68036 | 180 | 1100 | 1000 | 370 | 514 | 223 | 196 | 215 | 4 | A | B13 | 44,061 | 30 |
C | 70027 | 200 | 1150 | 1050 | 430 | 518 | 273 | 216 | 235 | 3 | A | B0 | 52,528 | 30 |
C | 70029 | 200 | 1150 | 1050 | 430 | 518 | 273 | 216 | 235 | 4 | A | B0 | 52,528 | 30 |
C | 71014 | 210 | 1250 | 1150 | 430 | 518 | 273 | 216 | 235 | 3 | A | B0 | 53,962 | 30 |
C | 71015 | 210 | 1250 | 1150 | 430 | 518 | 273 | 216 | 235 | 4 | A | B0 | 53,962 | 30 |
C | 72512 | 225 | 1250 | 1150 | 460 | 518 | 273 | 216 | 235 | 3 | A | B0 | 55,498 | 30 |
C | 72512R | 225 | 1250 | 1150 | 460 | 518 | 273 | 216 | 235 | 4 | A | B0 | 55,498 | 30 |
Group | Code | Capacity | CCA SAE | CCA EN | RC | L | W | H | TH | Layout | Terminal | Holddown | Weight | Pcs/plt |
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
24 | 24-550 | 60 | 550 | 480 | 100 | 258 | 172 | 200 | 220 | 10 | A | B1 | 15,972 | 90 |
24 | 24-600 | 70 | 600 | 540 | 110 | 258 | 172 | 200 | 220 | 10 | A | B1 | 17,070 | 90 |
24 | 24-630 | 75 | 630 | 600 | 120 | 258 | 172 | 200 | 220 | 10 | A | B1 | 17,560 | 90 |
24 | 24-700 | 80 | 700 | 680 | 140 | 258 | 172 | 200 | 220 | 10 | A | B1 | 18,514 | 90 |
24R | 24R-550 | 60 | 550 | 480 | 100 | 258 | 172 | 200 | 220 | 11 | A | B1 | 15,526 | 90 |
24R | 24R-600 | 70 | 600 | 540 | 110 | 258 | 172 | 200 | 220 | 11 | A | B1 | 17,070 | 90 |
24R | 24R-630 | 75 | 630 | 600 | 120 | 258 | 172 | 200 | 220 | 11 | A | B1 | 17,560 | 90 |
24R | 24R-700 | 80 | 700 | 680 | 140 | 258 | 172 | 200 | 220 | 11 | A | B1 | 18,514 | 90 |
25 | 25-500 | 55 | 500 | 480 | 90 | 231 | 172 | 200 | 220 | 10 | A | B1 | 14,474 | 90 |
25 | 25-550 | 60 | 550 | 480 | 100 | 231 | 172 | 200 | 220 | 10 | A | B1 | 14,921 | 90 |
35 | 35-500 | 55 | 500 | 480 | 90 | 231 | 172 | 200 | 220 | 11 | A | B1 | 14,474 | 90 |
35 | 35-550 | 60 | 550 | 480 | 100 | 231 | 172 | 200 | 220 | 11 | A | B1 | 14,921 | 90 |
27 | 27-630 | 75 | 630 | 600 | 130 | 303 | 172 | 200 | 220 | 10 | A | B1 | 19,178 | 7 |
27 | 27-670 | 80 | 670 | 640 | 140 | 303 | 172 | 200 | 220 | 10 | A | B1 | 19,870 | 75 |
27 | 27-750 | 90 | 750 | 720 | 150 | 303 | 172 | 200 | 220 | 10 | A | B1 | 20,796 | 75 |
27R | 27R-630 | 75 | 650 | 600 | 130 | 303 | 172 | 200 | 220 | 11 | A | B1 | 19,178 | 75 |
27R | 27R-670 | 80 | 700 | 640 | 140 | 303 | 172 | 200 | 220 | 11 | A | B1 | 19,870 | 75 |
27R | 27R-750 | 90 | 750 | 720 | 150 | 303 | 172 | 200 | 220 | 11 | A | B1 | 20,796 | 75 |
51 | 51-370 | 40 | 370 | 330 | 75 | 235 | 135 | 200 | 220 | 10 | A | B1 | 10,947 | 115 |
51 | 51-430 | 45 | 430 | 360 | 85 | 235 | 135 | 200 | 220 | 10 | A | B1 | 11,836 | 115 |
51R | 51R-370 | 40 | 370 | 330 | 75 | 235 | 135 | 200 | 220 | 11 | A | B1 | 10,947 | 115 |
51R | 51R-430 | 45 | 430 | 360 | 85 | 235 | 135 | 200 | 220 | 11 | A | B1 | 11,836 | 115 |
47 | 47-500 | 55 | 500 | 480 | 90 | 242 | 173 | 190 | 190 | 15 | A | B13 | 14,057 | 90 |
47 | 47-550 | 55 | 550 | 480 | 100 | 242 | 173 | 190 | 190 | 15 | A | B13 | 14,200 | 90 |
47 | 47-650 | 70 | 650 | 570 | 120 | 242 | 173 | 190 | 190 | 15 | A | B13 | 15,864 | 90 |
48 | 48-550 | 55 | 550 | 480 | 110 | 276 | 173 | 190 | 190 | 15 | A | B13 | 15,458 | 75 |
48 | 48-580 | 60 | 580 | 540 | 120 | 276 | 173 | 190 | 190 | 15 | A | B13 | 16,398 | 75 |
48 | 48-630 | 75 | 630 | 610 | 130 | 276 | 173 | 190 | 190 | 15 | A | B13 | 17,347 | 75 |
48 | 48-700 | 74 | 700 | 680 | 140 | 276 | 173 | 190 | 190 | 15 | A | B13 | 17,549 | 75 |
48 | 48-780-RU | 80 | 780 | 740 | 150 | 276 | 173 | 190 | 190 | 24 | A | B13 | 18,596 | 75 |
48 | 48-780R-RU | 80 | 780 | 740 | 150 | 276 | 173 | 190 | 190 | 1 | A | B13 | 18,596 | 75 |
49 | 49-750 | 90 | 750 | 720 | 147 | 353 | 173 | 190 | 190 | 15 | A | B13 | 21,512 | 60 |
49 | 49-800 | 92 | 800 | 760 | 167 | 353 | 173 | 190 | 190 | 15 | A | B13 | 22,235 | 60 |
58R | 58R-500 | 55 | 500 | 480 | 90 | 234 | 182 | 157 | 177 | 19 | A | B8 | 12,774 | 85 |
58 | 58-500 | 55 | 500 | 480 | 90 | 234 | 182 | 157 | 177 | 26 | A | B8 | 12,774 | 85 |
75 | 75-500 | 55 | 500 | 480 | 90 | 230 | 179 | 181 | 181 | 17 | SIDE | B1 | 13,467 | 90 |
75 | 75-550 | 60 | 550 | 480 | 100 | 230 | 179 | 181 | 181 | 17 | SIDE | B1 | 13,954 | 90 |
75 | 75-600 | 65 | 600 | 540 | 113 | 230 | 179 | 181 | 181 | 17 | SIDE | B1 | 14,768 | 90 |
75 | 75-650 | 70 | 650 | 570 | 120 | 230 | 179 | 181 | 181 | 17 | SIDE | B1 | 15,271 | 90 |
75DT | 75DT-500 | 55 | 500 | 480 | 90 | 230 | 179 | 181 | 201 | DT | B1 | 13,749 | 90 | |
75DT | 75DT-550 | 60 | 550 | 480 | 100 | 230 | 179 | 181 | 201 | DT | B1 | 14,237 | 90 | |
75DT | 75DT-600 | 65 | 600 | 540 | 113 | 230 | 179 | 181 | 201 | DT | B1 | 15,050 | 90 | |
75DT | 75DT-650 | 70 | 650 | 570 | 120 | 230 | 179 | 181 | 201 | DT | B1 | 15,553 | 90 | |
78 | 78-550 | 60 | 550 | 480 | 100 | 260 | 179 | 181 | 181 | 17 | SIDE | B1 | 14,913 | 80 |
78 | 78-600 | 65 | 600 | 540 | 113 | 260 | 179 | 181 | 181 | 17 | SIDE | B1 | 15,726 | 80 |
78 | 78-670 | 70 | 670 | 640 | 120 | 260 | 179 | 181 | 181 | 17 | SIDE | B1 | 16,240 | 80 |
78 | 78-750 | 75 | 750 | 720 | 130 | 260 | 179 | 181 | 181 | 17 | SIDE | B1 | 17,273 | 80 |
78DT | 78DT-550 | 60 | 550 | 480 | 100 | 260 | 179 | 181 | 201 | DT | B1 | 15,194 | 80 | |
78DT | 78DT-600 | 65 | 600 | 540 | 113 | 260 | 179 | 181 | 201 | DT | B1 | 16,008 | 80 | |
78DT | 78DT-670 | 70 | 670 | 640 | 120 | 260 | 179 | 181 | 201 | DT | B1 | 16,522 | 80 | |
78DT | 78DT-750 | 75 | 750 | 720 | 130 | 260 | 179 | 181 | 201 | DT | B1 | 17,555 | 80 | |
30H | 30H-830 | 100 | 830 | 760 | 180 | 326 | 172 | 203 | 223 | 10 | A | B1 | 23,135 | 60 |
4D | 4D-1000 | 150 | 1000 | 900 | 300 | 506 | 215 | 213 | 233 | 8 | A | B0 | 39,239 | 35 |
4D | 4D-1050 | 170 | 1050 | 950 | 322 | 506 | 215 | 213 | 233 | 8 | A | B0 | 41,698 | 35 |
8D | 8D-1200 | 200 | 1200 | 1100 | 430 | 509 | 274 | 220 | 240 | 8 | A | B0 | 50,989 | 30 |
8D | 8D-1400 | 220 | 1400 | 1300 | 460 | 509 | 274 | 220 | 240 | 8 | A | B0 | 55,121 | 30 |
22F | 22F-450 | 45 | 450 | 390 | 75 | 240 | 172 | 180 | 203 | 11F | DUAL FIT | B9 | 12,975 | 90 |
22F | 22F-450R | 45 | 450 | 390 | 75 | 240 | 172 | 180 | 203 | 11F | DUAL FIT | B9 | 12,975 | 90 |
22F | 22F-500 | 50 | 500 | 480 | 85 | 240 | 172 | 180 | 203 | 11F | DUAL FIT | B9 | 13,507 | 90 |
22F | 22F-500R | 50 | 500 | 480 | 85 | 240 | 172 | 180 | 203 | 11F | DUAL FIT | B9 | 13,507 | 90 |
22F | 22F-550 | 55 | 550 | 480 | 95 | 240 | 172 | 180 | 203 | 11F | DUAL FIT | B9 | 13,907 | 90 |
22F | 22F-550R | 55 | 550 | 480 | 95 | 240 | 172 | 180 | 203 | 11F | DUAL FIT | B9 | 13,907 | 90 |
31 | C31-750 | 90 | 750 | 720 | 160 | 330 | 172 | 217 | 240 | 18 | TOP | B0 | 23,064 | 60 |
32 | C31-800 | 95 | 800 | 760 | 170 | 330 | 172 | 217 | 240 | 18 | TOP | B0 | 23,566 | 60 |
33 | C31-850 | 100 | 850 | 800 | 180 | 330 | 172 | 217 | 240 | 18 | TOP | B0 | 24,211 | 60 |
34 | C31-950 | 105 | 950 | 900 | 185 | 330 | 172 | 217 | 240 | 18 | STUD | B0 | 25,514 | 60 |
35 | C31-1000 | 110 | 1000 | 900 | 190 | 330 | 172 | 217 | 240 | 18 | TOP | B0 | 25,997 | 60 |
36 | 31-1000L | 115 | 1000 | 900 | 190 | 330 | 172 | 217 | 238 | 11 | A | B1 | 25,926 | 60 |
31S | C31S-750 | 90 | 750 | 720 | 160 | 330 | 172 | 217 | 240 | 18 | STUD | B0 | 23,008 | 60 |
31S | C31S-800 | 95 | 800 | 760 | 170 | 330 | 172 | 217 | 240 | 18 | STUD | B0 | 23,511 | 60 |
31S | C31S-850 | 100 | 850 | 800 | 180 | 330 | 172 | 217 | 240 | 18 | STUD | B0 | 24,155 | 60 |
31S | C31S-950 | 105 | 950 | 900 | 185 | 330 | 172 | 217 | 240 | 18 | STUD | B0 | 25,458 | 60 |
31S | C31S-1000 | 110 | 1000 | 900 | 190 | 330 | 172 | 217 | 240 | 18 | STUD | B0 | 25,941 | 60 |
Group | Code | Capacity | CCA SAE | CCA EN | RC | L | W | H | TH | Layout | Terminal | Holddown | Weight | Pcs/plt |
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
M24 | M24-560 | 60 | 560 | 480 | 105 | 258 | 172 | 200 | 221 | 1 | TWIN | B1 | 16,569 | 90 |
M24 | M24-600 | 70 | 600 | 540 | 120 | 258 | 172 | 200 | 221 | 1 | TWIN | B1 | 17,404 | 90 |
M24 | M24-700 | 75 | 700 | 680 | 140 | 258 | 172 | 200 | 221 | 1 | TWIN | B1 | 18,848 | 90 |
M24 | M24-750 | 75 | 750 | 720 | 130 | 258 | 172 | 200 | 221 | 1 | TWIN | B1 | 18,680 | 90 |
M27 | M27-750 | 90 | 750 | 720 | 160 | 303 | 172 | 200 | 221 | 1 | TWIN | B1 | 21,120 | 75 |
M31 | M31-800 | 100 | 800 | 760 | 180 | 330 | 172 | 217 | 238 | 1 | TWIN | B0 | 23,686 | 60 |
M31 | M31-900 | 105 | 900 | 800 | 185 | 330 | 172 | 217 | 238 | 1 | TWIN | B0 | 24,969 | 60 |
M31 | M31-950 | 105 | 950 | 900 | 185 | 330 | 172 | 217 | 238 | 1 | TWIN | B0 | 25,614 | 60 |
